50 /80 /106 Gallon Solar Water Heater Storage Tank / Electric Water

1 Pressurized solar storage tank with or without heat exchange coil, with or without electrical heater element
Tank size:

• 50 gallon with one heat exchanger
• 50 gallon with no heat exchanger
• 80 gallon with no heat exchanger
• 106 gallon with no heat exchanger
• 106 gallon with heat exchanger

        50 GallonDiameter(in): 20Height(in): 60Insulation thickness(in): 2Inner vessel diameter(in): φ17inner vessel Material&thickness(mm):BTC340R 2.0Shell Material&thickness(mm): Galvanize sheet 0.5bottom heat exchange surface area: 1085Heat exchanger connecting pipe/tap: 5/8"Water pipe: NPT3/4"Back up heating power(KW) : 1.5Packing case size(in): 22*64Weight(lb): 190
80 GallonDimension(in): φ24Height(in): 60Inner vessel diameter(in): φ21inner vessel Material&thickness(mm):BTC340R 2.0Shell Material&thickness(mm): Galvanize sheet 0.5Insulation thickness(in): 2bottom heat exchange surface area: 1085Heat exchanger connecting pipe/tap: 5/8"Water pipe: NPT3/4"Back up heating power(KW) : 2.5Packing case size(in): 26*64Weight(lb): 260
106 GallonDimension(in): φ28Height(in): 66Inner vessel diameter(in): φ24inner vessel Material& thickness(mm):BTC340R 2.5Shell Material& thickness(mm): Galvanize sheet 0.5Insulation thickness(in): 2bottom heat exchange surface area: 1240Heat exchanger connecting pipe/tap: 5/8"Water pipe: NPT3/4"Back up heating power(KW) : 2.5Packing case size(in): 29*66Weight(lb): 290

SEA pressurized solar hot water storage tanks are very efficient in terms of energy saving and storage, as well as their long life time.  Each tank is made of thick coated galvanized steel exterior and patent porcelain enamel coating liner (Golden Dark-Blue Diamond Coating).
Each tank is insulated with high density polyurethane for maximum heat retention.  Also available are copper coil as the heat exchange collector loop.  The pressurized solar water tanks could be placed in series with the existing hot water heater that uses electric, gas, oil, or wood to heat water (which now could be used as a backup heating system providing extra hot water storage capacity).  When the water temperature is up to 140°F, the existing water heater remains off.
Golden Dark-Blue Diamond Coating, Ultimate protection  A porcelain enamel coating protects the tank against the corrosive effects of hot water.  The technology breakthrough Golden Dark-Blue Diamond coating formula is enriched with a higher level of zircon, producing a lining that is harder and more water-resistant than others in the industry.

These are solar water heater storage tank, with total 6 in/outlets: 2 for circulating with collector loop, 1 cold water in, 1 hot water out, that 4 in/outlets are on the side of the tank; 1 for T/P valve install that is on the top of the tank, 1 for drain valve install, that is at the bottom side of the tank.
